- Video Inputs: 4 CH，BNC （1.0Vp-p，75Ω），PAL/NTSC auto
- Audio Inputs: 4 CH RCA（2.0Vp-p，1kΩ）
- Video outputs: CVBS: 1 CH，BNC （ 1.0Vp-p， 75Ω）
- Audio Outputs: 1 CH RCA
- Resolution：PAL：960*576、NTSC：960*480
- VGA: Resolution：800*600, 1024*768，1280*1024, 1440*900
- HDMI: 1920*1080P, 800*600, 1024*768，1280*1024, 1440*900
- A/V decoder specifications: Compression: H.264
- Decoder resolution: 960H base（WD1/WHD1/WCIF ) or D1 base（D1/HD1/CIF ）
- Video Frame: PAL：25fps、NTSC：30fps
- Video Rate: Image Quality adjustable, Adjustable Rate, fixed Rate optional
- Stream: Double
- Audio compression: G.711A
- Dual stream: supported
- Playback: 1/4/8 ch at the same time, if for 8ch playback at the same time under 960H resolution
- Display: Supports S.E.Q., PIP, ZOOM
- Zoom: Live & Playback
- Record Mode: Continuous/Manual/Motion detect /Sensor/Alarm recording
- Back up: USB port savers (Pen Driver, Removable HDD & DVD-
|
- Free DDNS
- IR Extended
- Recording Mode: 960H/D1
- Feather Touch front panel
- 4CH video/4CH Audio
- MAC Player Software, Windows
- Remote view: MAC, IE, Google Chrome(IETAB)
- Mobile Software ASEE+, RXCAM
|
 |
|
